| 起源の場所: | 中国 |
|---|---|
| ブランド名: | YIZGEAR |
| 最小注文数量: | 1 セット |
| パッケージの詳細: | パライウッドの箱 |
| 受渡し時間: | 30日 |
| 支払条件: | L/C,T/T |
| 供給の能力: | 500セット/月 |
| スプラインのタイプ: | 直角型スプリング | ハードネス: | 220-260 HB |
|---|---|---|---|
| 製造のタイプ: | ギヤ粉砕 | 生産時間: | 30日 |
| 方法: | ギヤ歯切り工具で切ること | DIMENSION サイズ: | 標本または図形として |
| ハイライト: | custom spur gears with rectangular spline,hardened spur gears 220-260 HB,transmission gears with rectangular spline |
||
| Spline Type | Rectangular spline |
| Hardness | 220-260 HB |
| Manufacturing Type | Gear Grinding |
| Production Time | 30 Days |
| Method | Gear Hobbing |
| Dimension | As sample or drawing |
Spur gears are cylindrical gears with teeth parallel to the axis, and the teeth are distributed along the busbar direction of the cylinder, which is one of the most basic and common types of gear transmission.
When the active spur gear rotates, its teeth mesh with the teeth of the driven spur gear in turn, transmitting torque from the driving shaft to the driven shaft through the thrust between the tooth surfaces.
Ideal for equipment requiring simple transmission structure, including:
| Custom Made | ✓ |
| Gear Profile Type | Cylindrical Gears |
| Manufacturing | Gear Hobbing |
| Teeth Grinding | ✓ |
| Module (M) | Custom |
| Number of Teeth (Z) | Custom |
| Pressure Angle (α) | Custom |
| Helix Angle (β) | 0° |
| Accuracy Grade | ISO 6-7 Grade |
| Heat Treatment | Carburizing |
| Surface Hardness | 58-62 HRC |
| CHINA/GB | ISO | ГOCT | ASTM | JIS | DIN |
|---|---|---|---|---|---|
| 45 | C45E4 | 45 | 1045 | S45C | CK45 |
| 40Cr | 41Cr4 | 40X | 5140 | SCr440 | 41Cr4 |
| 20CrMo | 18CrMo4 | 20ХМ | 4118 | SCM22 | 25CrMo4 |
| 42CrMo | 42CrMo4 | 38XM | 4140 | SCM440 | 42CrMo4 |
| 20CrMnTi | 18XГT | SMK22 | |||
| 20Cr2Ni4 | 20X2H4A | ||||
| 20CrNiMo | 20CrNiMo2 | 20XHM | 8720 | SNCM220 | 21NiCrMo2 |
| 40CrNiMoA | 40XH2MA/40XHMA | 4340 | SNCM439 | 40NiCrMo6/36NiCrMo4 | |
| 20CrNi2Mo | 20NiCrMo7 | 20XH2MA | 4320 | SNCM420 |
